Model SSCF : Standard Xchange | ITT Standard | Xylem
Learn More About Model SSCF From Xylem, Standard Xchange
As the recognized leader in heat transfer products, systems and technology, The Standard Xchange model SSCF has been providing state-of-the-art solutions to heat transfer problems for more than 90 Years.
Today the company is devoted exclusively to the design, engineering and manufacture of shell-and-tube, gasketed plate, brazed plate and air-cooled heat exchanger products. Standard Xchange heat exchangers are engineered and manufactured by experienced craftsmen who have been devoted to the science of heat transfer not just for years, but for generations. And because we offer such a wide assortment of different heat exchanger designs, we can assure. you of getting the optimum heat transfer solution to your specific application, without bias toward any one particular (or proprietary) product line.
DETAILS on MODEL SSCF:
- Compact design with shell diameters 2″ to 8″, standard tube lengths 8″ to 72″ with custom tube lengths up to 144″.
- Available in 1, 2 and 4 tube side pass configurations.
- 1-2 Week Standard Lead-times with Expedite options for Same day or three day available for many units.
- ASME VIII Code available for most units.
- Flanged connection options also available.
ADVANTAGES TO USING MODEL SSCF
- Less costly than removable bundle heat exchangers.
- Provides maximum heat transfer surface area per given shell and tube size.
- Easily interchangeable with designs of various manufacturers.
- Flanged lip baffles ensure close tolerance, high efficiency and additional tube support.
- Enlarged bundle entrance area of hub/tubesheet design lowers entrance velocity and pressure loss.
- Tube side can be steam or mechanically cleaned.
- Only tube side fluids exposed to gaskets.
- No packed joints.
EXCHANGER TYPE
- Straight Tube
- Fixed Tubesheet
LIMITATIONS TO THE MODEL SSCF
- No provision for differential expansion of tubes and shell.
- Shell side may not be mechanically cleaned.
MATERIALS FOR THE MODEL SSCF
SHELL | 316 Stainless Steel |
TUBES | 316 Stainless Steel, With
Tube Diameter Options: 1/4″, 3/8″, and 5/8″ |
HUBS | 316 Stainless Steel |
BONNETS | Cast Stainless Steel 316 with Cast Iron and Cast Bronze options |
FEET & BOLTING | Carbon Steel with Stainless options |
SSCF/SSCF-C STANDARD DESIGN CAPABILITIES – STANDARD X-CHANGE – ITT STANDARD
Design Pressure | Design Temperature | |
|---|---|---|
Tube Side | 150 psi
10.5 kg/cm² | 450 °F
232 °C |
Shell Side | 225 psi
15.8 kg/cm² | 450 °F
232 °C |
